POLI-TAPE® POLI-FLEX® IMAGE DIMENSION Heat Transfer Vinyl

POLI-TAPE® POLI-FLEX® IMAGE DIMENSION (FDC Series DIM) is a casted, plotter cuttable polyurethane vinyl with high-quality matte surface finish. Due to the thickness of 600 μ optical attractive 3D-transfers result. It’s suitable for transfer onto textiles like cotton, mixtures of polyester/cotton and polyester/acrylic. This film can be used for lettering on T-shirts, sport and leisure wear, sport bags, and promotional articles.

Description
Key Features
Colors
Roll Sizes
Resources
Video
Part Number

POLI-TAPE® POLI-FLEX® IMAGE DIMENSION (FDC Series DIM) is a casted, plotter cuttable polyurethane vinyl with high-quality matte surface finish. Due to the thickness of 600 μ optical attractive 3D-transfers result. It's suitable for transfer onto textiles like cotton, mixtures of polyester/cotton and polyester/acrylic. This film can be used for lettering on T-shirts, sport and leisure wear, sport bags, and promotional articles.

Additional information

FDC Series	DIM
Subcategory	3D Effect
Brand	POLI-TAPE®
Film Technology	Cast, Polyurethane
Film Thickness	10.5 mil
CPSIA Compliant	No
Application - Materials	Cotton, Poly/Cotton Blends, Polyester
Finish	Gloss, Raised (3D effect)
Blockout	No
Adhesive	Clear, Permanent (Heat-Activated)
Liner	PET
Cutting	Yes
How to Cut	45° Knife Recommended
Printing	No
Layer	No
Preheat Garment	No
Minimum Application Temperature	320°F
Application Time	15 Seconds
Pressure	44 PSI Medium Pressure
Peel	Warm
Shelf Life	1 Year

Colors

Standard

Reveal

Roll Sizes

Part No.		Roll Size
STANDARD COLORS
-1510* (*special order)		15"x10Yds
-6010		60"x10Yds
REVEAL COLORS
-1230		12"x30Yds
-2030* (*special order)		19.7"x30Yds
-4030		39.4"x30Yds
ALL COLORS
-1205		12"x5Yds
-1210		12"x10Yds

Resources

POLI-TAPE® POLI-FLEX® IMAGE DIMENSION Technical Data Sheet

Type: pdf

POLI-TAPE® POLI-FLEX® IMAGE DIMENSION REVEAL Technical Data Sheet

Type: pdf

POLI-FLEX® IMAGE Sample Card - FDC +POLI-TAPE®

Type: pdf

Part Number

HOW TO BUILD A PART NUMBER

0000-0000-000

THE FIRST SET OF CHARACTERS in our part numbers identifies the series of products by letters and determines the conversion process. Increasing the non-perforated product number by 50 identifies most perforated products.

THE SECOND SET OF CHARACTERS identifies the color by letters and/or numbers.

THE THIRD SET OF CHARACTERS identifies the material converted size. The first two numbers indicate the width, and the last two numbers indicate the length.
