FDC Series: 5101
3M™ 5100R Scotchlite™ Reflective Graphic Film

3M™ 5100R Scotchlite™ Reflective Graphic Film

3M™ 5100R Scotchlite™ Reflective Graphic Film is FDC 5101 Series. These films are removable, enclosed lens, retroreflective, engineer-grade films that offer flexibility and excellent angularity. Use these long-term durable films for decals, commercial and non-regulated signage, vehicle markings, emblems, and striping on vertical, flat, or curved surfaces with or without rivets. To order punched material, use part number 5151.

3M™ 5100R Scotchlite™ Reflective Graphic Film is FDC 5101 Series. These films are removable, enclosed lens, retroreflective, engineer-grade films that offer flexibility and excellent angularity.

Distributors: Check the price book for all current details including sizes, colors, and minimums.

Additional information

Brand

3M™

UV Inkjet

N/A

Minimum Application Temperature

50 w/o rivets / 55 w/ rivets

Interior / Exterior

Interior and Exterior

Steel Rule

Yes

Flat Bed

Yes

Sheetable

Yes

Laminate

Cold

Computer Cut

Yes

Wet Apply

No

Solvent

N/A

Eco Solvent

N/A

Shelf Life

2 Years

Screen

Yes

FDC Series

5101

Film Technology

Retroreflective

Film Thickness

7

Finish

Gloss

Blockout

Yes

Outdoor Durability

7 Years

Adhesive

Removable (Up to 3 Years) / Clear

Liner

Polyethylene Coated LF

Conformability

Flat and simple curves, rivets

Product Type

Reflective

Subcategory

Reflective

Roll Sizes

Part No.Roll Size
-481548"x50Yds
-480348"x10Yds
-301530"x50Yds
-300330"x10Yds
-241524"x50Yds
-240324"x10Yds
-151515"x50Yds
-150315"x10Yds

Colors

010-White
010-White
014-Orange
014-Orange
064-Gold
064-Gold
065-Rich Gold
065-Rich Gold
071-Yellow
071-Yellow
072-Red
072-Red
074-Royal Purple
074-Royal Purple
075-Blue
075-Blue
076-Light Blue
076-Light Blue
077-Green
077-Green
078-Light Green
078-Light Green
079-Brown
079-Brown
081-Lemon Yellow
081-Lemon Yellow
082-Ruby Red
082-Ruby Red
085-Black
085-Black

Part Number

HOW TO BUILD A PART NUMBER

0000-0000-000

THE FIRST FOUR DIGITS in our part numbers identify the series of products and determine the converting process. Increasing the non-perforated product number by 50 identifies most Perforated products.

THE SECOND FOUR DIGITS identify the material converted size. The first two digits indicate the width and the last two digits indicate the length.

THE FINAL THREE DIGITS identify the color and all colors contain three digits.
